MT710L 4G LTE Cat 1 bis Mini GPS Tracker

MT710L is an IP68 waterproof GPS tracker that uses 4G LTE Cat 1 bis, which can provide super-low power consumption of up to 300 days standby time powered by internal batteries. Users can track the unit in real-time via their mobile phone or PC anytime, anywhere. It has been widely used in sports events, personal, pets, asset tracking, and other industries.

1. Features

• 4G LTE Cat 1 bis (no 2G/3G fallback)
• 300 days battery life (one report per day)
• IP68 Waterproof
• Live tracking
• Low Power Alarm
• SOS alerts
• Charging alert
• Smart Motion Detection
• Scheduled Timing Report
• GPS+WiFi+LBS Positioning
• Programmable via Web/USB/SMS
• Open Protocol & Easy to Integrate

2. Applications

• Sports Events
• Personal Tracking
• Pets Tracking
• Asset Tracking

3. In the box

Standard Accessories

• 1* MT710L GPS Tracker (white)
• 1* Magnetic charging cable (white)

Optional Accessories

• 1* Pet Collar(black)
• 1* Silicone Case (Glow in the Dark )
• 1* Lanyard (black)
• 1* USB Config Cable (black wire)

Note: For each order (regardless of quantity), we will provide only one free USB config cable. If you need more USB Config cables, please order them from this link.

4. Specification

5. Interface

6. Installation

• Check the LED status until access to the 4G network.
• Get ready a Nano SIM Card (4G) with 30MB data a month;
• Open the back cover with the screwdriver;
• Insert SIM Card and close the back cover

7. GPS Tracking Platform

• http://www.trackits.com (Click “Demo” auto-login)

8. User Manual & Catalog

• User Manual
• Datasheet
• Protocol (same as MT710)
• Working Mode (same as MT710)
• Commands List
• FCC & CE certification in progress

9. Battery life (Backup battery is 650mAh and based on Mode 3)

• 1 hour report interval, work for 18 days
• 2 hours report interval, work for 47 days
• 3 hours report interval, work for 78 days
• 4 hours report interval, work for 85 days
• 6 hours report interval, work for 98 days
• 8 hours report interval, work for 128 days
• 12 hours report interval, work for 273 days
• 24 hour report interval, work for  300days

• Q: Can I integrate the device with a third-party server?
• A: Sure, our protocol is open. Click here to download the protocol. After integration, the device will communicate directly with your server and no longer report data to our server.

• Q: Do you have a free tracking platform available for testing?
• A: Sure, the MT710L is already compatible with Traccar (port 5030), gps-trace(port 30184 ), gpwox(port 6030).

• Q: SOS Button function?
• A: Press for 3 seconds to report SOS and press for 8 seconds to power on/off.

• Q: Which SIM card is best for this GPS tracker?
• A: Get a 4G LTE data SIM with about 30 MB/month, and choose the EU or LA version that matches your region. A band match is necessary but not sufficient: the carrier must also run 4G LTE on one of those bands where you use the tracker. We recommend the Mictrack IoT SIM Card — check your country in the coverage list.

• Q: Which third-party platforms are compatible with this 4G GPS tracker?
• A:  Most third-party platforms are already compatible with the Mictrack MT710L. Click here for details.

• Q: How do I config the device for first-time use?
• A: You can setup your device via SMS (if supported by the SIM card) . If your sim card is data only you can setup the deivce via the USB Config tool ( Click this post to see how to set up the MT710L vis USB Config tool) If you can share your SIM card APN with us, we can config it for you before shipment, so you won’t need to set it up when you receive your MT710l.

• Q: What are the supported commands for the device?
• A: Here is a list of all the supported commands, including SMS, USB, and Downlink commands. Click here for details.

• Q: What protocols are supported by this device?
• A: It supports TCP and UDP.

• Q: What is the procedure for the Home Mode setup?
• A: Check this post.

• Q: What frequency bands are supported by the device?
• A: It supports all following bands:

MT710L-EU (Europe, Middle East, Africa, Asia-Pacific, Oceania): B1/B3/B5/B7/B8/B20/B28

MT710L-LA (North and Latin America): B2/B3/B4/B5/B7/B8/B28/B66

• How to Calculate Battery Voltage into Percentage?
• A: Check this post to get more detail.

• Q: How to track my order?
• A: You can click this link and then input your order number (for examples #2023) and your email to check.
